pin	func	note	app
2	VCC	power
4	GND	power
1	I/O1	general purpose I/O
3	I/O2	general purpose I/O
5	I/O3	general purpose I/O
6	I/O4	general purpose I/O
7	I/O5	general purpose I/O
8	I/O6	general purpose I/O
