MT2492-dat

2A High-Efficiency Synchronous Step-Down Converter

MT2492

Aerosemi Technology Co., Ltd 1

600KHz, 16V，2A Synchronous Step-Down Converter

FEATURES

 High Efficiency: Up to 96%
 600KHz Frequency Operation
 2A Output Current
 No Schottky Diode Required
 4.5V to 16V Input Voltage Range
 0.6V Reference
 Slope Compensated Current Mode Control for Excellent Line and Load Transient Response
 Integrated internal compensation
 Stable with Low ESR Ceramic Output Capacitors
 Over Current Protection with Hiccup-Mode
 Thermal Shutdown
 Inrush Current Limit and Soft Start
 Available in SOT23-6 Package
 -40°C to +85°C Temperature Range
