camera-SDK-dat

• I2C-dat

• camera-dat

• micropython-dat

• https://github.com/espressif/esp32-camera

Arduino IDE

If you are using the arduino-esp32 core in Arduino IDE, no installation is needed! You can use esp32-camera right away.

board

• ESP1000-dat - SCM1030-dat

ESP32

• official code camera - CameraWebServer.ino

repro

• opencv-dat - openMV-dat

• circuitpython-dat - better support for ESP32-S3-dat not well support for ESP32-CAM == SCM1030-dat == https://github.com/adafruit/Adafruit_CircuitPython_OV2640/issues/22

• https://github.com/alanesq/esp32cam-demo

• https://github.com/yoursunny/esp32cam

  • WifiCam
  • AsyncCam
  • https://github.com/emannuell/ESP32-CAM-OV2640
• https://github.com/donny681/ESP32_CAMERA_QR
• https://github.com/ArduCAM/Arduino

esp32-cam-micropython-2022

https://github.com/shariltumin/esp32-cam-micropython-2022

https://github.com/shariltumin/esp32-cam-micropython-2022/blob/main/Christmas-2023-Edition/scripts/cam_config.py

https://github.com/Edragon/esp32-cam-micropython-2022

micropython-dat - script-based-SDK-dat

• esp-idf-dat

• https://github.com/Edragon/esp-idf-code

OV2640

• OV2640-lemariva-dat

namato/micropython-ov2640 == only support SPI OV2640 camera

• https://github.com/namato/micropython-ov2640

  git clone https://github.com/namato/micropython-ov2640 640 sudo ampy -p /dev/ttyUSB0 put boot.py sudo ampy -p /dev/ttyUSB0 put main.py sudo ampy -p /dev/ttyUSB0 put ov2640_constants.py sudo ampy -p /dev/ttyUSB0 put ov2640_hires_constants.py sudo ampy -p /dev/ttyUSB0 put ov2640_lores_constants.py sudo ampy -p /dev/ttyUSB0 put ov2640.py

Then initialize and capture still frames using code like this. The included main.py contains an example.

import ov2640 cam = ov2640.ov2640() nbytes = cam.capture_to_file("/image.jpg")

A good way to retrieve files for testing/verification is rshell-dat.

sudo rshell -p /dev/ttyUSB0 Connecting to /dev/ttyUSB0 ... Welcome to rshell. Use Control-D to exit. /home/namato/micropython-ov2640> /home/namato/micropython-ov2640> cp /image2.jpg .

This will copy the newly created image locally for viewing.

dependency

• freeRTOS-dat

repo

• https://github.com/Edragon/Camera
• https://github.com/Edragon/esp32-camera-series
• https://github.com/Edragon/esp32-camera-screen

ref

• camera-dat

• camera-SDK - SDK

setup

AI-Thinker esp32-cam board

ai_thinker = {PIN_PWDN:32,
              PIN_RESET:-1,
              PIN_XCLK:0,
              PIN_SIOD:26,
              PIN_SIOC:27,
              PIN_D7:35,
              PIN_D6:34,
              PIN_D5:39,
              PIN_D4:36,
              PIN_D3:21,
              PIN_D2:19,
              PIN_D1:18,
              PIN_D0:5,
              PIN_VSYNC:25,
              PIN_HREF:23,
              PIN_PCLK:22,
              XCLK_MHZ:16,
              PIXFORMAT:5,
              FRAMESIZE:10,
              JPEG_QUALITY:10,
              FB_COUNT:1,
}

Electrodragon esp32s3-cam board (default in firmware)

Electrodragon = {PIN_PWDN:-1,
            PIN_RESET:-1,
            PIN_XCLK:15,
            PIN_SIOD:4,
            PIN_SIOC:5,
            PIN_D7:16,
            PIN_D6:17,
            PIN_D5:18,
            PIN_D4:12,
            PIN_D3:10,
            PIN_D2:8,
            PIN_D1:9,
            PIN_D0:11,
            PIN_VSYNC:6,
            PIN_HREF:7,
            PIN_PCLK:13,
            XCLK_MHZ:14,
            PIXFORMAT:5,
            FRAMESIZE:10,
            JPEG_QUALITY:12,
            FB_COUNT:2,
}

Lilygo T-camera V1.6 esp32s3-cam board (default in firmware)

lilygo = {PIN_PWDN:-1,
        PIN_RESET:39,
        PIN_XCLK:38,
        PIN_SIOD:5,
        PIN_SIOC:4,
        PIN_D7:9,
        PIN_D6:10,
        PIN_D5:11,
        PIN_D4:13,
        PIN_D3:21,
        PIN_D2:48,
        PIN_D1:47,
        PIN_D0:14,
        PIN_VSYNC:8,
        PIN_HREF:18,
        PIN_PCLK:12,
        XCLK_MHZ:14,
        PIXFORMAT:5,
        FRAMESIZE:10,
        JPEG_QUALITY:12,
        FB_COUNT:2,
}
