NE555 DAT

• input voltage up to 12 (16)V

https://www.ti.com/lit/ds/symlink/ne555.pdf

T = 1.1C = 1.1 * 500 000 * 0.000047 = 25.85 seconds

tuning pulse

• used on board SCU1063-dat

• output control by D4184-dat mosfet-dat

ref

• pulse-generator-dat
