MicroCore-dat

== https://github.com/MCUdude/MicroCore == star 580

Enter the following URL in Additional Boards Manager URLs:

https://mcudude.github.io/MicroCore/package_MCUdude_MicroCore_index.json

Open the Tools > Board > Boards Manager... menu item.
Wait for the platform indexes to finish downloading.
Scroll down until you see the MicroCore entry and click on it.
Click Install.
After installation is complete close the Boards Manager window.
avrdude-dat - ISP-dat

System wide configuration file is C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\etc\avrdude.conf

set AVRDUDE_CONF="C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\etc\avrdude.conf"

avrdude -v -C %AVRDUDE_CONF% -c arduino -P com245 -p t13 -b 19200 avrdude -v -C %AVRDUDE_CONF% -c stk500v1 -P com245 -p t13 -b 19200

C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\bin\avrdude.exe -v -C "C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\etc\avrdude.conf" -c stk500v1 -P com245 -p t13 -b 19200

pref == -c stk500v1 -P com245 -p t13 -b 19200

C:\Users\Administrator>C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\bin\avrdude.exe -v -C "C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\etc\avrdude.conf" -c stk500v1 -P com245 -p t13 -b 19200

Avrdude version 8.0-arduino.1
Copyright see https://github.com/avrdudes/avrdude/blob/main/AUTHORS

System wide configuration file is C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\etc\avrdude.conf

Using port            : com245
Using programmer      : stk500v1
Setting baud rate     : 19200
AVR part              : ATtiny13
Programming modes     : SPM, ISP, HVSP, debugWIRE
Programmer type       : STK500
Description           : Atmel STK500 v1
HW Version            : 2
FW Version            : 1.18
Topcard               : Unknown
Vtarget               : 0.0 V
Varef                 : 0.0 V
Oscillator            : Off
SCK period            : 0.0 us
XTAL frequency        : 7.372800 MHz

AVR device initialized and ready to accept instructions
Device signature = 1E 90 07 (ATtiny13, ATtiny13A)

Avrdude done.  Thank you.

Processing -U hfuse:w:0xeb:m

Reading 1 byte for hfuse from input file 0xeb in 1 section [0, 0] Writing 1 byte (0xEB) to hfuse, 1 byte written, 1 verified

write fuse

-c stk500v1 -P com245 -p t13 -b 19200 -U hfuse:w:0xeb:m

C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\bin\avrdude.exe -v -C "C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\etc\avrdude.conf" -c stk500v1 -P com245 -p t13 -b 19200 -U hfuse:w:0xeb:m

C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\bin

avrdude.exe -v -C "C:\Users\Administrator\AppData\Local\Arduino15\packages\MicroCore\tools\avrdude\8.0-arduino.1\etc\avrdude.conf" -c stk500v1 -P com245 -p t13 -b 19200 -U hfuse:w:0xeb:m
