An I2S (Interactive Two-Way Serial) interface is a type of serial communication protocol used for transferring data between devices.
It is commonly used in computer networking, as well as in audio processing and digital electronics.
I2S interfaces typically use a combination of fast and slow data transfer rates to make efficient use of communication bandwidth and minimize noise and errors.
One of the key features of I2S interfaces is their ability to support full-duplex communication, which allows for the simultaneous transfer of data in both directions.
This makes I2S a popular choice for high-speed data transfer applications.
Pin
| Name | also Name | func | RPI GPIO | RPI pin |
|---|---|---|---|---|
| BCLK | Bit clock line | G18 | PIN 12 | |
| WS | LRCK | Word clock line | G19 | PIN 35 |
| SD | SDIN / SDOUT | At least one multiplexed data line | G21 | PIN 40 |
Solution
ref
https://en.wikipedia.org/wiki/I%C2%B2S
