PCA9685-dat

board

• SDR1090-dat - SDR1087-dat

• SDR1062-dat

• MPC1114-dat

Info

chip info, datasheet, etc.

The PCA9685 is an I²C-bus controlled 16-channel LED controller optimized for Red/Green/Blue/Amber (RGBA) color backlighting applications.

16-channel, 12-bit PWM Fm+ I2C-bus LED controller

• 16CH PWM-dat output
• A0~A5 I2C-dat address setup

SCH

4X motors control by 2X TB6612-dat

• TB6612-dat

App.

• servo-dat

demo code

• https://github.com/adafruit/Adafruit-PWM-Servo-Driver-Library

ref

• TLC5940-dat

• I2C-dat

• NXP-dat

• PCA9685
